Giới thiệu
IES2210-4P2GC-2P24-60W là bộ chuyển mạch Ethernet công nghiệp không quản lý lớp 2, cung cấp 4 cổng POE Ethernet 100M, 2 cổng Combo Gigabit, hỗ trợ nguồn 24VDC, nguồn POE 60W.
IES2210 Series hỗ trợ nguồn điện AC/DC tùy chọn, có nguồn điện DC đầu vào là hai mạch cung cấp điện độc lập có thể đảm bảo hoạt động bình thường của thiết bị khi một nguồn điện gặp sự cố. Thiết kế của công tắc DIP có thể thực hiện điều khiển luồng, cổng với tốc độ chỉ định 10M và cảnh báo. Khi sự cố liên kết của cổng xảy ra, đèn báo ALM sẽ sáng lên và gửi cảnh báo, trong khi đó, thiết bị báo động được kết nối với rơ le sẽ gửi cảnh báo để xử lý sự cố hiện trường nhanh chóng.
Phần cứng của IES2210 Series sử dụng thiết kế không quạt, tiêu thụ điện năng thấp, nhiệt độ và điện áp rộng và đã vượt qua các thử nghiệm tiêu chuẩn công nghiệp nghiêm ngặt, có thể phù hợp với môi trường cảnh công nghiệp với các yêu cầu khắc nghiệt đối với EMC. IES2210-8T2GC-2P48 có thể được sử dụng rộng rãi trong lưới điện thông minh, vận chuyển đường sắt, thành phố thông minh, thành phố an toàn, năng lượng mới, sản xuất thông minh và các lĩnh vực công nghiệp khác.
Đặc trưng
- Hỗ trợ 4 cổng POE Ethernet 100M, 2 cổng Combo Gigabit
- Công suất tối đa của cổng PoE đơn là 30W
- Nguồn POE: 60W
- Nguồn: 24VDC
- Nhiệt độ hoạt động: -40 ~ 75℃
Thông số kỹ thuật
Standard & Protocol |
IEEE 802.3 for 10Base-TIEEE 802.3u for 100Base-TX
IEEE 802.3ab for 1000Base-T
IEEE 802.3z for 1000Base-X
IEEE 802.3x for Flow Control
IEEE 802.3af for PoE
IEEE 802.3at for PoE+ |
PoE |
The maximum power of single PoE port: 15/30WThe power supply pin of PoE: V+, V+, V-, V- correspond to Pin 1, 2, 3, 6 |
Interface |
100M copper port: 10/100Base-T(X), RJ45, Flow Control, Full/half Duplex Mode, MDI/MDI-X AutotunningCombo port: 10/100/1000Base-T(X) or 1000Base-X
Console port: CLI command line management port (RS-232), RJ45
Alarm port: 6-pin 5.08mm pitch terminal blocks, including 2-pin alarm terminal blocks, support 1 relay alarm output, current carrying capacity is 1A@30VDC or 0.3A@125VAC |
LED Indicator |
Running Indicator, Port Indicator, Power Supply Indicator, Alarm Indicator, PoE Indicator (only for PoE products) |
Switch Property |
Transmission mode: store and forwardMAC address: 8K
Packet buffer size: 1Mbit
Backplane bandwidth: 7.6G
Switch time delay: <10μs |
Power Requirement |
Optional 24VDC, 48VDC or 220VAC, 6 pins 5.08mm pitch terminal blocks, including 4 pins power supply terminal blocksDC dual power supply redundancy, anti-reverse connection |
Power Consumption |
lNo-load: ≤4.9W@48VDClFull-load: ≤122.8W@48VDC |
Environmental Limit |
Operating temperature range: -40~75℃Storage temperature range: -40~85℃
Relative humidity: 5%~95% (no condensation) |
Physical Characteristic |
Housing: IP40 protection, metalInstallation: DIN-Rail or wall mounting
Dimension (W x H x D): 53mm×138mm×110mm
Weight: ≤0.62kg |
Industrial Standard |
IEC 61000-4-2 (ESD), Level 3Air discharge: ±8kV
Contact discharge: ±6kV
IEC 61000-4-4 (EFT), Level 3
Power supply:±2kV
Ethernet port: ±1kV
Relay: ±2kV
IEC 61000-4-5 (Surge), Level 3
Power supply: common mode±2kV, differential mode±1kV
Ethernet port: common mode±2kV, differential mode±1kV
Relay: common mode±2kV, differential mode±1kV
Shock: IEC 60068-2-27
Free fall: IEC 60068-2-32
Vibration: IEC 60068-2-6 |
Các sản phẩm cùng Series
Model |
Cổng Combo Gigabit |
Cổng Ethernet 100M |
Cổng Ethernet POE 100M |
Nguồn điện |
Nguồn POE |
IES2210-8T2GC-2P48 |
2 |
8 |
|
12~48VDC dual power supply |
|
IES2210-8T2GC-P220 |
2 |
8 |
|
85~264VAC single power supply |
|
IES2210-4T2GC-2P48 |
2 |
4 |
|
12~48VDC dual power supply |
|
IES2210-4T2GC-P220 |
2 |
4 |
|
85~264VAC single power supply |
|
IES2210-8P2GC-2P24-120W |
2 |
|
8 |
24VDC dual power supply |
120W |
IES2210-8P2GC-2P48-120W |
2 |
|
8 |
48VDC dual power supply |
120W |
IES2210-8P2GC-2P48-240W |
2 |
|
8 |
48VDC dual power supply |
240W |
IES2210-4P2GC-2P24-60W |
2 |
|
4 |
24VDC dual power supply |
60W |
IES2210-4P2GC-2P24-120W |
2 |
|
4 |
24VDC dual power supply |
120W |
IES2210-4P2GC-2P48-120W |
2 |
|
4 |
48VDC dual power supply |
120W |
